TECHNICAL SPECIFICATION
| TECHNICAL SPECIFICATION | |||
|---|---|---|---|
| Pin Distance | 18 mm | Body Material | PA (+G) |
| Nominal Voltage | Adapting Plug | Form “A” | |
| AC | Max.250V | Gasket Material (Opt.) | Operating Temp. |
| DC | Max.300V | Nitrile/TPE | -40oC + 90oC |
| Nominal Current | 10A | Silicon | -40oC + 125oC |
| Contact Resistance | Max.20 m Ohms | Product Weight | 10.00 gm |
| MAX.Conduc.Cross-Sect | 01.0 mm2 | Packing | 25 Nos. with fixing Screw & Gsk. |
TECHNICAL DIAGRAM
